Week 1, Tuesday

-

Software/circuit:


  • Quick crash course in Arduino and electronics (ALL)
  • Experimenting with spare Arduino (MALCOLM)
  • Ran through the code to understand all parts of it (ALL)
  • Managed to get all 3 thermistors working accurately at the same time (LANA)
  • Schematic was finished and now the board layout is being worked on (VITO)

CAD

  • Getting familiar with Autodesk Fusion 360 by trying to design given objects
    • Zach - wagon
    • Guery - sword & car
    • Luis - sword
  • Rail support was printed, but turned out too heavy out of the printer in the TECH building
    • Priority 1 was to shed as much weight as possible by shrinking and cutting after marking all places that we can change to reduce weight.
    • As many eyes as possible are needed on this to make sure we are not missing any obvious and/or unneeded pieces (JOSH&IAN)
    • We will try printing on the LulzBot in the Research Center

Camera crew:

  • Located a probable cause in the crashing
    • GoPros will shut off at 125F, so ways to keep the temperature low while allowing clear visibility are being looked at (GREG&NAMI)
